Designed for extended operational life and minimal maintenance in harsh industrial environments.
Achieves smooth, continuous airflow with minimal pulsation, ideal for aeration and gas boosting.
Precision balancing of impellers and compact frame reduce vibration and operating noise.
Customizable number of stages and impeller sizes based on flow rate and pressure requirements.
Easy disassembly and access for routine inspection and servicing without extensive downtime.
| Parameter | Value Range |
|---|---|
| Flow Rate | 2.5 – 200 m³/min |
| Pressure Rise | 30 – 200 kPa |
| Number of Stages | 2 – 8 |
| Impeller Speed | Up to 10,000 RPM |
| Housing Material | Cast Iron (standard), optional coatings available |
| Drive Type | Belt drive / direct coupling |
| Lubrication | Oil-lubricated bearings |
For diffused aeration systems in municipal and industrial plants.
Cement kilns, lime kilns, and biomass incinerators.
Ash handling systems and cooling air blowers.
Safe delivery of clean air or non-corrosive gases.
For plastic pellets, cement, fly ash, and more.
Cast iron body resists wear and thermal stress over years of operation.
Low total cost of ownership thanks to reduced maintenance cycles.
Delivers clean, dry, and stable airflow under dynamic load conditions.
Widely used in municipal and industrial applications around the world.
The C Series offers a highly flexible flow rate range, operating efficiently between 2.5 and 200 m³/min depending on configuration.
The design allows for customizable configurations between 2 to 8 stages, tailored exactly to your specific flow and pressure specifications.
Cast iron provides exceptional robustness and durability. It resists wear, mechanical stress, and thermal deformation under continuous operations in tough industrial environments.
It is commonly used in wastewater treatment plants for aeration, power stations for ash handling, petrochemical plants for gas delivery, and various pneumatic conveying systems.
No. The blower features a maintenance-friendly layout that ensures quick disassembly, allowing easy access for routine bearing lubrication, inspection, and servicing to minimize downtime.
Operation noise and vibration are minimized through precision balancing of the multistage impellers and a heavy, compact cast iron frame layout.
