Cheap Foam Slurry Pump - Optimized for Frothy Slurry Handling in Flotation and Mineral Processing Applications Manufacturers, Companies

The Foam Slurry Pump, also known as a Froth Pump, is specifically engineered for transporting foamy slurries generated during flotation and mineral separation processes. With its unique vertical design, oversized inlet, and defoaming hopper structure, this pump effectively minimizes foam buildup, ensuring continuous and efficient pumping.

Whether you're dealing with flotation concentrate, deinking froth, or viscous frothy slurries, our foam slurry pump offers stable performance, wear resistance, and superior air-handling capability â€” critical for maximizing plant uptime and productivity.

Send Inquiry

Product Description

Key Features & Technical Advantages

Anti-Foam Hopper Design

Integrated large-volume hopper allows the foam to break naturally before entering the pump casing, improving feeding consistency.

Vertical Cantilever Structure

No submerged bearings or seals, ideal for handling corrosive and abrasive slurries without excessive wear.

Open or Semi-Open Impeller

Designed to handle high air content and large particle sizes without clogging or cavitation.

Heavy-Duty Construction

All wetted parts are available in high chrome alloy or natural rubber for excellent abrasion resistance.

Reliable Shaft Support System

Shaft and bearings are supported above the mounting base, extending lifespan in frothy, corrosive environments.

Technical Specifications

Parameter	Value
Flow Rate	7 – 650 m³/h
Head	5 – 40 meters
Foam Slurry Density	Up to 1.3 g/cm³
Submerged Depth	800 – 2500 mm (customizable)
Material Options	Cr26 high chrome, natural rubber
Motor Power	5.5 – 75 kW
Drive Type	Direct drive, V-belt

Application Industries

Mineral Flotation Plants

Transfer of froth concentrate or scavenger froth slurry.

Non-Ferrous Metal

Handling foamy copper, zinc, lead flotation output.

Paper & Pulp Industry

Deinking process and foam slurry handling.

Chemical Plants

For phosphoric acid production involving foam separation.

Frequently Asked Questions

How does the Anti-Foam Hopper design improve operational efficiency?

The integrated large-volume hopper allows the foam to break down naturally before it enters the pump casing. This significantly improves feeding consistency and prevents blockages.

What are the benefits of the vertical cantilever structure?

The vertical cantilever structure does not require submerged bearings or seals. This design eliminates seal failure risks and makes it ideal for handling corrosive and abrasive slurries without excessive wear.

What material options are available for abrasive slurries?

All wetted parts are customizable and available in high chrome alloy (Cr26) or natural rubber, providing excellent resistance to severe wear and corrosion.

What is the maximum foam slurry density this pump can handle?

The system is designed to handle high air content and frothy slurries with a density of up to 1.3 g/cm³.

What drive options are supported for these pumps?

The pumps support both direct drive and V-belt drive configurations to match different space requirements and performance parameters.
